Designed as a cruiser racer style yacht for a former light displacement mono hull race yacht owner. This yacht has fulfilled his needs as a yacht that could be cruised to and fro from major Australia east coast regattas and also for the odd trip to Asia and the South Pacific. with 18 months since launch this vessel has travelled many thousands of ocean miles carrying out this owners dream. This is a robust vessel but of light displacement with construction from foam cored epoxy composites with some use of carbon in main load areas.

• Multi hull yachts
• Lidgard Yacht Design Web Site Directory
• Lidgard home page
• contact

Clickany thumb nail image below
          to view a larger image and then
Back  to return again

                 43FT PERFORMANCE CRUISING CATAMARAN

                            PRINCIPAL DIMENSIONS


LIGHT SHIP DISPLACEMENT    ....................................  6720 kg
LOA                                         .................................... 13.000 MTRS
BEAM MAX.                              ....................................   7.800 MTRS
DRAFT   CENTER BOARD             ..................................  1.200 MTRS
DRAFT    FIXED KEEL                    ................................. 2.175 MTRS
WING DECK CLEARANCE                  ...........................   0.900 MTRS
SAIL AREA MAIN & FORE TRIANGLE   ..........................  98.5 m2 ~ 111 m2
SPONS.WL BEAM / DWL             ....................................  1.76 : 1
RATE OF SINKAGE AT DWL     KG  PER  C M    ...........  226 kg
